Matrice 30 Series, DJI Dock, DJI FlightHub 2, Zenmuse H20N Announcement
We are excited to share with you that today DJI launches the Matrice 30 Series drone the all-in-one solution for professional drone operators that for the first time puts a powerful flying platform in the service of a fully remote fleet management system and an autonomous docking and recharging station. This integrated solution unlocks powerful new functionality for Enterprise drone usersˈ allowing them to build next-generation operations that finally unlock the full potential of DJI’s transformative technology.
Matrice 30 Series Drone
The M30 series drones (including M30 and M30T) are integrated with multiple high-performance sensors, lightweight and portable, and weatherproof. Equipped with DJI RC PLUS enterprise remote control and the newly upgraded DJI Pilot 2 flight app for an improved piloting efficiency and flight safety.
Unique aerial intelligence to capture everything
The M30 Series integrates wide, zoom, and thermal cameras (M30T only) with a laser rangefinder, which together can capture the aerial data you need, when you need it.
Wide Camera
Equivalent Focal Length: 24 mm, DFOV: 84°
12 MP 1/2” CMOS Sensor
Video Resolution: 4K/30fps
Zoom Camera
48 MP 1/2” CMOS Sensor
5×-16× Optical Zoom
200× Max. Hybrid Zoom
Photo Resolution: 8K
Video Resolution: 4K/30fps
Thermal Imaging Camera
Equivalent Focal Length: 40 mm
Resolution: 640×512
Frame Rate: 30fps
Measurement Accuracy: ±2°C or ±2%
Laser Rangefinder
Range: 3 m – 1200 m
Accuracy: ±(0.2m+D×0.15%)
Powerful Flight Performance
A balance of power and portability delivers higher operational efficiency.
Max Flight Time: 41-min
Wind Resistance: 15 m/s
Service Ceiling: 7000 m
Max Speed: 23 m/s
Environmental Adaptability
With IP55 protection, the M30 can easily handle adverse weather and temperatures ranging from -20° C ~ 50° C.
Safe and Reliable
Dual-vision and ToF sensors appear on all six sides of the aircraft, keeping it and your mission safe. The built-in ADS-B receiver provides timely warnings of any incoming crewed aircraft nearby.
Enhanced Transmission
Four built-in antennas support OcuSync 3 Enterprise, which enables triple-channel 1080p video transmission, and seamless swapping between input feeds, even in complex environments. Bolster your connection with DJI Cellular Module, an optional 4G dongle that supports stable video transmission in complex, or remote work environments.
Lightweight and Portable
Compact and foldable, the M30 Series is easy to pack up, carry, and deploy.
BS30 Intelligent Battery Station
A smart, portable solution with multiple charging modes to meet your mission needs. Capable of charging four pairs of TB30 Intelligent Flight Batteries and one pair of RC Plus batteries, pairs are charged one at a time, with one pair taking just 30 minutes to charge from 20-90%.
TB30 Intelligent Flight Battery
Each battery supports self-heating for cold environments, hot-swapping for fast turnarounds, and 400 charge cycles for increased operational efficiency.
DJI Cellular Module
Provides 4G based transmission link between the drone and remote controller, while also enabling internet connection for the remote controller.
DJI Dock
DJI Docks are rugged, reliable, and are built to operate 24/7, day or night, rain or shine. Each DJI Dock houses a Matrice 30 where it lands, recharges, takes off, and executes missions programmed in DJI FlightHub 2.
Complete Cloud Control
With FlightHub 2, unlock full DJI Dock functionality from the cloud. Schedule missions, create and edit flight routes, and manage data collected.
Fast Charging, Fast Turnaround
Fast charge and take off thanks to TEC air conditioning that cools the drone batteries, enabling charging from 10-90% in just 25 minutes.
Day or Night, Rain or Shine
DJI Docks are built to withstand the elements, so you don’t have to.
Ingress Protection: IP55
Operating Temperature: -35° C to 50° C
Surge Protection: 40kA
Backup Battery: 5 Hours
Active Temperature Control: For fast charging and drone safety
6 Months Maintenance Interval
Simple Setup
DJI Docks weigh less than 100 kg and have a <1 square meter footprint. Setup requires ground fixation, access to power and internet, and quick configuration via the DJI RC Plus remote controller.
DJI FlightHub 2
FlightHub 2 is an all-in-one cloud-based drone operations management platform that helps you achieve comprehensive, real-time situational awareness. Access all the information you need to plan drone missions, supervise your fleet, and manage the data you create, now from a secure cloud-based environment.
2.5D Base Map
Integrate elevation data with satellite maps to bring terrain awareness to your operation planning.
One-Tap Panorama Sync
Create a 360° overview and upload to the cloud with a single tap. Shared panoramas, and the coordinates they were captured from, are placed on your mission’s 2.5D Base Map, granting all team members quick aerial awareness.
Cloud Mapping
Generate RGB or infrared orthomosaic maps of areas up to 1.5 km² in a single flight. Orthomosaics are automatically overlaid on your 2.5D Base Map, granting you detailed awareness of your mission environment whenever needed.
Mission Live Streaming
Connect multiple users to one or many drone operations simultaneously, and keep teams updated with the latest developments thanks to low latency, high-resolution live streaming.
Live Annotations
Highlight objects or areas of interest for efficient mission management and resource distribution. Annotations are visible to ground teams, pilots, or any team member for timely project alignment and task distribution. It also supports cloud-based route planning, media management and can be used with DJI Dock for remote operations.
Zenmuse H20N
The Zenmuse H20N integrates starlight sensors into its zoom and wide-angle cameras. Pair this with dual zoom thermal cameras and a laser rangefinder, and you have a versatile hybrid payload that rises to the occasion. Combine these with the Matrice 300 and rise beyond the cover of darkness.
Sensors Upgraded Across Multiple Dimensions
Infrared Zoom
Dual Thermal Cameras
Resolution: 640×512
2x Zoom (Equivalent Focal Length: 53 mm)
8x Zoom (Equivalent Focal Length: 196 mm)
See the Big Picture
Night Vision Wide Camera
Starlight Sensor: 2MP
Stronger Low-Light Performance
Pierce Through the Veil
Night Vision Zoom Camera
Starlight Sensor: 4MP
20× Optical Zoom, 128× Max Zoom
Low-Light Details
Precise Distance Data
Laser Rangefinder
Range: 3 m to 1200 m
Accuracy: ± (0.2 m + D×0.15%)
